SDC-10M
This highly efficient switch mode step-down DC-DC converter converts an input voltage of 24 VDC nominal (range 18 VDC to 32 VDC) to a highly regulated output voltage of 12 VDC nominal (13.8 VDC) at 8 Amps and is also having an extra MEMORY BACKUP output of 100mA @ 12Vdc. The SDC-10M DC-DC converter is non-isolated (no galvanic isolation between input and output) and meant for use in negative ground systems. Features include short circuit, reverse polarity and overvoltage protection.
✓ Innovative product design
✓ ISO 9001-2015 certified
✓ Strict Quality Control
Quotation Within 24 Hours
- Description
- Product benefits
- Documentation
Description
| Input Voltage | 18 to 32 VDC |
| Output Voltage | 13.8Vdc + 12Vdc for the memory output |
| Dimensions | 98 x 100 x 49 mm |
| Output | 8 Amps + 100mA for output |
| Fuse Rating | 10 Amps |
| Weight | 0,25 Kgs |
- Advanced switchmode design
- Compact and light weight
- Reverse polarity protection
- Overvoltage protection
- Extra 100mA output for example MEMORY backup
- 2 year warranty
| Language | File | Type |
| n.a. | SDC-10M.jpg | Image |
 |
SDC-10M_slicksheet.pdf | Specifications |
